| PRODUCT TYPE |
Industrial isolated USB to RS485 converter |
| HOST PORT |
USB |
| DEVICE PORT |
RS485
|
| BAUDRATE
|
1200bps ~ 460800bps |
| USB |
| Operating Voltage |
5V |
| Connector |
USB-B |
| Protection |
500mA resettable fuse, output isolation |
|
| ISOLATED RS485 |
| Connector |
Screw terminal |
| Direction Control |
Hardware automatic control |
| Protection |
600W lightning proof and surge-suppress, 15KV ESD protection (onboard 120R matching resistors) |
| Transmission Mode |
Point-to-multi-points (up to 32 nodes, it is recommended to use repeaters for 16 nodes or more) |
|
| INDICATORS |
| PWR |
Power indicator, lights up while the USB is connected and voltage is detected |
| ACT |
Status indicator, lights up green while the driver is detected. |
| RXD |
RXD indicator, lights up when the device ports send data back |
| TXD |
TXD indicator, lights up when the USB port is sending data |
|
| OPERATING ENVIRONMENT |
| Temperature |
-40 ~ 85℃ |
| Humidity |
5%RH ~ 95%RH |
|
| OPERATING SYSTEM |
Win7/8/8.1/10/11, Mac, Linux, Android |
